Zebra ZC300 Series Dual-Sided Card Printer
₹86,599.00
| Material Brand |
Zebra
|
| Model Name/Number |
ZC300
|
| Material |
Plastic
|
| Print Resolution |
300dpi
|
| Flash Memory |
2GB
|
| Operating Humidity |
20-80%
|
| Operating Temperature Deg Celsius |
15-35 Degree Celsius
|
| Storage Temperature |
-5 to 70 Degree Celsius
|
| Size |
258x157x383mm
|
| Double Sided Weight |
4.4kg
|
| Weight |
4kg(Single sided)
|
Description
ZC300 Card Printer
Specifications
STANDARD FEATURES
• 300 dpi (11.8 dots/mm) print resolution
• 2 GB flash memory
• Image size: 1006 x 640 pixels
• Auto calibration of ribbon
• USB 2.0 and Ethernet 10/100 connectivity
• 100 card capacity auto-adjusting input hopper (30 mil)
• 100 card capacity output hopper (30 mil)
• Manual card feeding capability with LED bezel
• Graphical color LCD
• 3 Tricolor printer status indicator lights
• Kensington® secure lock slot
• Print Touch NFC tag for online printer help and
documentation access
• Printer host authentication
• Data encryption
• Three-year limited warranty on printer and printhead
Printing Specifications
• Dye-sublimation thermal transfer direct to card print method
• Full-color or monochrome printing
• Single and dual-sided printing
• Edge-to-edge printing on standard CR-80 media
Printing throughput (cards per hour) based on batch printing
with USB connectivity. Times may vary depending on the
computer configuration.
• 900 cards/hour single sided monochrome
• 200 cards/hour single-sided YMCKO
• 140 cards/hour dual-sided YMCKOK
• 450 cards/hour dual sided monochrome
Media Specifications
| Supplies Specifications: | NOTE: The ZC300 printer is designed to work only with Zebra genuine ribbons. Ribbons are included in a simple-to-load recyclable cartridge. |
| Ribbon Description | Cartridge Image Count |
| YMCKO* | 200 |
| YMCKO* | 300 |
| YMCKOK* | 200 |
| ½ YMCKO* | 400 |
| ½ YMCKOKO2 | 250 |
| YMCKLL* | 200 |
| YMCPKO* | 200 |
| SrDYMCKO* | 200 |
| KrO* | 700 |
| KdO* | 700 |
| Black Monochrome* | 2000 |
| Black Monochrome | 1500 |
| White Monochrome* | 1500 |
| Red Monochrome | 1500 |
| Blue Monochrome | 1500 |
| Gold Monochrome | 1500 |
| Silver Monochrome | 1500 |
| Ribbon availability may vary by region. *Zebra intelligent technology automatically detects and authenticates ribbon • Cleaning roller is included with each ribbon • Two available cleaning kit options: your choice of two (2) or five (5) isopropyl alcohol cleaning cards (1,000 images/card) Card Compatibility: NOTE: For optimum print quality and printer performance, use of Genuine Zebra supplies is recommended. • Card Thickness: 10-40 mil* • Card Size: CR80 ISO 7810 ID-1 format, CR79* • Card Material: PVC and PVC composite • Adhesive back and writable back cards *Note: Spot color or monochrome printing recommended only on >20 mil thick cards and CR79 cards. |
Physical Characteristics
| imensions |
Single Sided |
| Weight |
Single Sided |
Operating Characteristics
| Operating Temp. | 59º F to 95º F/15º C to 35º C |
| Storage Temp. | 23º F to 158º F/-5º C to 70º C |
| Operating Humidity | 20% to 80% non-condensing |
| Media Storage | — Temperature: 41º F to 77º F/5º C to 25º C — Humidity: 35% to 65% non-condensing |
| Electrical | • Auto-switching single-phase AC power • Operating range: 90-132VAC and 190-264VAC RMS • Frequency range: 47-63 Hz • FCC Class A |
Communications and Interface Capabilities
|
USB 2.0 |
Standard |
| Built-in 10/100 Ethernet | Standard |
| 802.11ac | Optional |
Encoding Options and Specifications
Magnetic stripe encoder — ISO 7811 (new and pre-encoded; tracks 1, 2, and 3; high and low coercivity; stripe down and stripe up with duals-sided printers)3,4
• Combined MIFARE ISO 14443 AandB (13.56MHz) contactless encoder with
1 SAM Slot and optional support for reading iCLASS ISO 15693 and ISO 7816
cards, and ISO 7816 Contact Encoder with EMV level 1 certification, and
PC/SC compliance3, 4
• ISO 7816 Smart Card Contact Station for third party external
contact encoders3
• EPCglobal Gen 2 UHF RFID encoder3, 4
Additional Optional Features
• Card flipper for dual-sided printing3
• 10 card reject bin is standard with dual-sided printers3
• Lockable enclosure3
Footnotes
1. Specialty ribbon availability varies by region
2. 1/2 YMCKOKO available in APAC only
3. Field upgradeable options
4. Single-wire communication available
Specifications subject to change without notice.
Printer Drivers
| Microsoft Windows Certified |
Windows Server 2008 (32 and 64 bit), Windows 7 (32 bit and 64 bit) Windows 8 and Windows 8.1 (32 bit and 64 bit compatible) Windows Server 2012 (64 bit) Windows 10 (32 bit and 64 bit) Windows Server 2016 Windows drivers include: • Color coded printer status indicators for the operator • Black panel extraction and controls for specialty ribbon panels with image preview • Configuration utility to limit access by operators to change image quality and printer settings • Advanced printer configuration, security settings and diagnostics capabilities |
| Linux | Ubuntu 16..X (64 Bit) |
| Apple | MAC OS X 10.13.X (64 bit) |
| Please see www.zebra.com for an up-to-date listing of supported systems. |
Markets and Applications
General Access Control
- Employee badges
Education
- Access control cards for identification and facility access for K-12 and higher education campuses
Retail/Hospitality
- Membership cards
- Events and season passes
- Guest and passenger cards
- Food safety labeling
Financial Services
- Credit cards
- Debit cards
